TW-18A series instruments are compact, cost-effective, portable and high dynamic range Mini Optical Time Domain Reflectometer (OTDR). By providing all the measurement functions and performance required for optical fiber construction and maintenance, it is designed for full-range fiber fault detection to solve FTTx, CATV and optical LANs problems.

Features

• Fault event(s) analysis

• Real-Time status display

• 7’’ Color TFT  LCD  Touch Screen

• High resolution and dynamic range

• Mapping function with actual position display

• Rugged, Sealed design for most challenging environments

• Portable, and User friendly interface

• USB ports for data transfer and storage

• Powered by rechargeable Li-ion battery or AC/DC adaptor

• 650nm Visual Fault Locator (VFL)

• Modulated Light Source and Power Detection function





• Splicing loss detection

• Fiber attenuation measurement

• Fiber acceptance test

• Fiber break point locating

• Fiber length measurement

• On-Line monitoring

• Fiber identification
